| Hot Stamping Machine Control |
| Idec Box Part List |
| AFM Part# 105208 |
| Part # | Description | Manu PN | PDF Files | Sales Price | | 105208 | Control Box, Hot Stamp, Idec PLC | 19070_Idec_Box_Assembly | View PDF 1 | $4,000.00 |  |  |  | | |
|
| Part Number | Description | Qty | Units | Unit
Sales Price | Total
Sales Price | Manufacturer | Manu PN | VendorNo | PDF |
| 100119 | Plug, 9pin, Female, Panel Moun | 1 | EA | $2.40 | $2.40 | AMP | 206705-1 | CIRCOMP | No PDF | |  |  |  | | |
| 100541 | Fuse, 1 Amp, 3AG | 1 | EA | $0.25 | $0.25 | Littlefuse | 0312001.HXP | NEWARK | No PDF | |  | | | | |
| 102748 | Fuse Cover, Red, for Franklin | 1 | EA | $1.33 | $1.33 | Littlefuse | 03480001Z | MOUSER | No PDF | |  |  |  | | |
| 102797 | Relay, DPDT, 110VAC RH2B | 3 | EA | $7.81 | $23.43 | Idec | RH2B-UAC110-120V | STEVEN | No PDF | |  |  |  | | |
| 102800 | Chassis, Hot Stamp Control Box | 1 | EA | $34.95 | $34.95 | CD Alexander | 001SS | CDALEXA | View PDF 1 | |  |  |  | | |
| 102801 | Top Cover, Hot Stamp Control B | 1 | EA | $68.92 | $68.92 | CD Alexander | 002SS | CDALEXA | View PDF 1 | |  |  |  | | |
| 102811 | Relay, SPDT 24 VDC No Diode,RH1B | 3 | EA | $6.42 | $19.26 | Idec | RH1B-UDC24V | STEVEN | No PDF | |  |  |  | | |
| 102812 | Plug, 7 Pin, Female | 1 | EA | $7.19 | $7.19 | AMP | 206137-1 | CIRCOMP | No PDF | |  |  | | | |
| 102849 | Fuse Holder, Square, Franklin | 1 | EA | $4.88 | $4.88 | Littlefuse | 03480870Z | MOUSER | No PDF | |  |  |  | | |
| 103072 | Pilot Light, Green, 120vac | 1 | EA | $17.09 | $17.09 | Idec | HW4P-1FQD G-120V | STEVEN | No PDF | |  |  |  | | |
| 103110 | Pilot Light Red 120V | 1 | EA | $13.31 | $13.31 | Idec | HW4P-1FQD R-120V | STEVEN | No PDF | |  |  |  | | |
| 103258 | Power Supply, 24vdc, 2.5A | 1 | EA | $58.21 | $58.21 | Idec | PS5R-VD24 | STEVEN | No PDF | |  |  |  | | |
| 103604 | Feed-through terminal block UT 4 GREY | 8 | EA | $0.97 | $7.76 | Phoenix Contact | 3044102 [Alternate for 3045130 ] | STEVEN | No PDF | |  | |  | | |
| 103605 | End clamp - E/NS 35 N | 3 | EA | $1.25 | $3.75 | Phoenix Contact | 0800886 | STEVEN | No PDF | |  | |  | | |
| 104155 | Circuit Breaker 1Pole 1A 277VAC/80VDC | 1 | EA | $25.00 | $25.00 | Carling Technologies | AA1-B0-34-410-1B1-C | BEYONDC | No PDF | |  |  |  | | |
| 104317 | Hot Stamp Control Board Assembly, PC Board | 1 | EA | $35.00 | $35.00 | AFM Engineering, Inc. | 19060 | LINDAVE | No PDF | |  |  | | | |
| 105172 | Switch, Selector, 2 Position, Maintained, 1 N/O | 2 | EA | $0.00 | $0.00 | Idec | HW1S-2TF10 | STEVEN | No PDF | |  |  |  | | |
| 105207 | 3.8 PLC+HMI Color Silvr Bezel | 1 | EA | $342.60 | $342.60 | Idec | FT1A-C12RA-S | STEVEN | No PDF | |  |  | | | |
| Total Parts Price | | | | $0.00 | $0.00 | | | $4,000.00 | |
| Part List Price | | | | | $1,094.20 | | | | |
|
|
